DJI Ronin 4D 6k & 8K- Top 10 Q&A

Q: 1. What exactly is the DJI Ronin 4D? 🤔

The DJI Ronin 4D is a revolutionary professional cinema camera system. It integrates a full-frame Zenmuse X9 gimbal camera (6K or 8K) with an advanced 4-axis stabilization system, including a Z-axis arm for exceptionally smooth footage. It combines imaging, stabilization, and focusing, ideal for solo cinematographers and professional crews.

Q: 2. What are the main differences between the Ronin 4D 6K and 8K versions? 📊

The main differences are sensor capabilities and maximum recording resolutions. The 6K version records up to 6K/60fps, while the 8K version records up to 8K/75fps. Both share the same core body, 4-axis stabilization, LiDAR focusing, internal ND filters, and DJI DL Mount, but differ in price. The choice depends on resolution needs and budget.

Q: 3. What makes the Ronin 4D's stabilization unique? ✨

The Ronin 4D's stabilization is unique due to its 4th axis (Z-axis), a vertical stabilization arm. This, combined with ActiveTrack Pro and various sensors, actively dampens vertical jarring movements (like walking or running), resulting in Steadicam-like smoothness directly from the camera, reducing the need for extensive post-production stabilization.

Q: 4. What lens mounts are compatible with the Ronin 4D? Lenses Lenses Lenses 📸

The Ronin 4D features an interchangeable lens mount system. It natively supports DJI's DL Mount for their full-frame prime lenses. Official adapters are available for Leica M and Sony E mounts, and PL mount lenses can also be used via specific configurations or adapters, offering broad lens compatibility.

Q: 5. What video formats and codecs does the Ronin 4D support? 🎞️

The Ronin 4D supports professional video formats including Apple ProRes RAW (license required), Apple ProRes 4444 XQ, ProRes 422 HQ, ProRes 422, and H.264 (4:2:0 10-bit). It records to CFexpress Type B cards or the DJI PROSSD 1TB module.

Q: 6. How long does the battery last, and how is it charged? 🔋

The Ronin 4D uses DJI TB50 Intelligent Batteries. A single battery provides up to 2.5 hours of recording under ideal conditions, or 1.5-2 hours with typical usage. TB50 batteries are charged using a dedicated hub, taking about 1.5 hours per battery.

Q: 7. What is the weight and size of the Ronin 4D? Is it easy to handle? 💪

The Ronin 4D main body with camera, lens, battery, and top handle weighs roughly 4.67 kg (approx. 10.3 lbs). While heavier than typical mirrorless setups, its design with intuitive handgrips and Z-axis stabilization makes handheld operation manageable. Support systems like an Easyrig are recommended for extended use.

Q: 8. How does the LiDAR Focusing System work? 🎯

The LiDAR Focusing System uses a LiDAR Range Finder to project laser points and measure their reflection time, creating a real-time 3D depth map. This enables fast, accurate autofocus, even in low light or on low-contrast subjects, and supports Automated Manual Focus (AMF) up to 10 meters.

Q: 9. Can the Ronin 4D be used for remote operation or live streaming? 📡

Yes, the Ronin 4D supports remote operation via DJI's O3 Pro video transmission (up to 6 km range) for monitoring, gimbal control, and settings adjustment. For live streaming, its HDMI output can be connected to compatible streaming encoders.

Q: 10. What is the approximate price range for the DJI Ronin 4D? 💰

The DJI Ronin 4D 6K Combo typically starts around $6,800 - $7,200 USD. The 8K Combo usually starts around $11,500 USD. Prices vary by retailer and included accessories. Additional costs for lenses, batteries, and licenses should be considered.

April 22, 2025 BIKMAN TECH

EN | DE | FR | ES | IT | NL | SV | DA | FI | NO | PL | JA | KO | AR | TR | HI | ID | PT

Considering an investment in a cutting-edge professional cinema camera like the DJI Ronin 4D? You're in the right place! At BIKMAN TECH, we understand thorough research is key. That's why we've created this comprehensive DJI Ronin 4D FAQ, answering the top 10 questions about this innovative camera system. This guide will provide crucial insights into the Ronin 4D's groundbreaking 4-axis stabilization, Zenmuse X9 full-frame camera (available in 6K and 8K versions), LiDAR focusing system, and much more, whether you're a professional cinematographer or a high-end content creator exploring its capabilities.

1. What exactly is the DJI Ronin 4D? 🤔

The DJI Ronin 4D stands out as a revolutionary professional cinema camera system. Its core innovation is the seamless integration of a full-frame Zenmuse X9 gimbal camera (offered in 6K and 8K models) with an advanced 4-axis stabilization system. This system surpasses traditional 3-axis gimbals by incorporating a Z-axis arm, which actively counteracts vertical camera shake. This results in exceptionally smooth footage, akin to using a Steadicam, even during dynamic actions like walking or running. The Ronin 4D elegantly combines imaging, stabilization, and focusing into one cohesive unit, ideal for both solo cinematographers and larger professional film crews looking for unparalleled stability and image quality.

2. What are the main differences between the Ronin 4D 6K and 8K versions? 📊

The primary differences between the DJI Ronin 4D 6K and 8K versions lie in their sensor capabilities and maximum recording resolutions, directly impacting image quality and workflow options:

Feature	Ronin 4D 6K	Ronin 4D 8K
Max Resolution	6K (6008×3168)	8K (8192×4320)
Max Frame Rate	Up to 6K/60fps, 4K/120fps	Up to 8K/75fps, 4K/120fps
Sensor	Full-Frame CMOS	Full-Frame CMOS
Dynamic Range	Claimed 14+ stops	Claimed 14+ stops
Internal ND	Built-in 9-stop physical ND filters	Built-in 9-stop physical ND filters
Lens Mount	Interchangeable (Native DJI DL Mount)	Interchangeable (Native DJI DL Mount)
Price Point	Generally lower	Generally higher

Both the Ronin 4D 6K and Ronin 4D 8K models share the same robust core body, innovative 4-axis stabilization, precise LiDAR focusing system, and versatile modular design. Your decision between the 6K and 8K versions will primarily hinge on your specific resolution needs for video production and your project budget.

3. What makes the Ronin 4D's stabilization unique? ✨

The stabilization on the DJI Ronin 4D is truly unique due to its pioneering 4th axis (Z-axis). While traditional gimbals offer 3-axis stabilization (pan, tilt, and roll), the Ronin 4D adds a vertical stabilization arm. This advanced Z-axis stabilization, working with ActiveTrack Pro technology, utilizes downward and forward-facing sensors, along with IMU, gyroscope, and barometer data. This actively dampens vertical jarring movements often encountered when walking or running, producing footage with remarkable Steadicam-like smoothness straight out of the camera. This significantly minimizes the need for cumbersome rigging or time-consuming post-production stabilization, streamlining your filmmaking workflow.

4. What lens mounts are compatible with the Ronin 4D? Lenses Lenses Lenses 📸

The DJI Ronin 4D offers excellent lens versatility thanks to its interchangeable lens mount system, a crucial feature for professional cinematographers.

Native DL Mount: The Ronin 4D is equipped with DJI's proprietary DL Mount. This mount supports a selection of lightweight, full-frame DJI DL prime lenses (such as 24mm, 35mm, and 50mm F2.8), designed for optimal performance with the system.
Adapted Mounts: DJI provides official lens mount adapters for popular systems like Leica M and Sony E mounts. Furthermore, compatibility with industry-standard PL mount cinema lenses is achievable through specific adapters or configurations. This broad lens compatibility allows filmmakers to leverage their existing lens collections or choose the perfect glass for their production. Note that autofocus capabilities and electronic controls may vary based on the specific lens and adapter combination.

5. What video formats and codecs does the Ronin 4D support? 🎞️

Designed for demanding professional video production, the DJI Ronin 4D supports a range of high-quality video formats and codecs:

Apple ProRes RAW: For maximum image data and post-production flexibility, ProRes RAW recording is available on both the Ronin 4D 6K and 8K models (requires a separate license purchase).
Apple ProRes: It offers robust support for various Apple ProRes codecs, including ProRes 4444 XQ, ProRes 422 HQ, and ProRes 422, ensuring high-fidelity capture.
H.264 (4:2:0 10-bit): This more compressed codec is available for workflows where smaller file sizes are crucial or for creating proxy files.

To handle these high-resolution and data-intensive recording formats, the Ronin 4D utilizes fast internal storage options: CFexpress Type B cards or the dedicated DJI PROSSD 1TB module. These ensure reliable recording at the highest quality settings.

6. How long does the battery last, and how is it charged? 🔋

The DJI Ronin 4D is powered by DJI TB50 Intelligent Batteries, which are also compatible with other professional DJI equipment like the Ronin 2 gimbal and Inspire 2 drone, offering convenience for existing DJI users.

Ronin 4D Battery Life: Under optimal conditions (e.g., room temperature, with features like LiDAR and wireless transmission disabled), a single TB50 battery can provide up to 2.5 hours of continuous recording. However, typical real-world usage, engaging features like active LiDAR focusing, continuous 4-axis stabilization, and external monitoring, will likely yield runtimes closer to 1.5 to 2 hours.
Charging TB50 Batteries: These batteries are charged using a DJI-specific charging hub, capable of charging multiple TB50 batteries concurrently. Each battery takes approximately 1.5 hours to achieve a full charge. For uninterrupted shooting on professional sets, investing in several batteries and a multi-battery charging hub is highly recommended.

7. What is the weight and size of the Ronin 4D? Is it easy to handle? 💪

The DJI Ronin 4D is a robust and substantial piece of professional camera equipment, engineered for optimal stability and top-tier performance.

DJI Ronin 4D Weight: The main camera body, when equipped with the Zenmuse X9 gimbal camera, a lens, a TB50 battery, and the top handle, has a weight of approximately 4.67 kg (around 10.3 lbs). This figure does not include additional accessories like external monitors or microphones.
Handling and Ergonomics: Although the Ronin 4D is an integrated system, its weight is more significant than a standard mirrorless or DSLR camera mounted on a separate gimbal. However, its ergonomic design, featuring intuitive handgrips and the crucial benefit of Z-axis stabilization, makes handheld operation surprisingly manageable, particularly when compared to traditional cinema camera setups with similar capabilities. For prolonged shooting periods, utilizing support systems such as an Easyrig is often advisable to enhance operator comfort and stability.

8. How does the LiDAR Focusing System work? 🎯

A standout feature of the DJI Ronin 4D is its groundbreaking LiDAR (Light Detection and Ranging) focusing system, which revolutionizes autofocus capabilities for cinema cameras.

How LiDAR Focusing Works: The system employs a sophisticated LiDAR Range Finder module. This module projects thousands of invisible laser points onto the subject and scene. By precisely measuring the reflection time of these points, the Ronin 4D generates a real-time 3D depth map of its surroundings.
Advantages of LiDAR Autofocus: This advanced technology delivers exceptionally fast, accurate, and reliable autofocus (AF) performance. It excels even in challenging low-light environments or when focusing on subjects with low contrast, situations where traditional phase-detect or contrast-detect AF systems often falter. Furthermore, the LiDAR system enables Automated Manual Focus (AMF). In AMF mode, the focus wheel intelligently rotates in sync with changes in the focus point, providing operators with the tactile feedback of manual focus combined with the precision of autofocus. The LiDAR system maintains accurate focus for subjects up to 10 meters (approximately 33 feet) away.

9. Can the Ronin 4D be used for remote operation or live streaming? 📡

Absolutely, the DJI Ronin 4D is engineered with comprehensive connectivity options for modern filmmaking workflows, including robust remote operation and live streaming capabilities.

Remote Camera Operation: The Ronin 4D incorporates DJI's advanced O3 Pro video transmission technology. This system provides a reliable, low-latency (as low as 68ms) video feed over distances of up to 6 km (approximately 20,000 feet) line-of-sight when used with the High-Bright Remote Monitor. This enables full remote control capabilities, including monitoring the live feed, adjusting gimbal movements, and changing camera settings. Remote focus pulling is also seamlessly supported via the DJI Three-Channel Follow Focus or by utilizing the intuitive LiDAR waveform displayed on the remote monitor.
Live Streaming with Ronin 4D: While the Ronin 4D does not feature built-in direct RTMP streaming, it facilitates live broadcasting. The HDMI output port, available on both the main camera body and the remote monitor, can be connected to compatible third-party streaming encoders. This allows integration into various live broadcast and production workflows.

10. What is the approximate price range for the DJI Ronin 4D? 💰

As a premium professional filmmaking tool, the DJI Ronin 4D price reflects its sophisticated technology and comprehensive feature set. Here's an approximate price range:

DJI Ronin 4D 6K Combo Price: The 6K version typically starts in the range of $6,800 - $7,200 USD. This combo generally includes the Ronin 4D main body, the Zenmuse X9-6K gimbal camera, LiDAR Range Finder, High-Bright Main Monitor, handgrips, top handle, one TB50 battery, and a carrying case.
DJI Ronin 4D 8K Combo Price: The 8K version usually starts around $11,500 USD. This package includes the same core components as the 6K combo but features the higher-resolution Zenmuse X9-8K gimbal camera.

It's important to note that these prices can fluctuate based on the retailer, specific bundle inclusions (such as the DJI PROSSD, lens packages, or the 4D Video Transmitter), and any current promotions. Prospective buyers should also budget for additional expenses such as lenses, extra TB50 batteries, and software licenses (e.g., for Apple ProRes RAW).

We trust this detailed DJI Ronin 4D FAQ has illuminated the exceptional capabilities and features of this groundbreaking professional cinema camera. The Ronin 4D, with its integrated Zenmuse X9 camera, 4-axis stabilization, and LiDAR focusing, is genuinely pushing the boundaries of modern cinematography. Have more questions about the Ronin 4D, or wish to share your own experiences using this innovative system? Please leave a comment below! BIKMAN TECH is committed to helping you discover the ideal technology for your creative and professional projects. Explore current offers and find the best deals for the DJI Ronin 4D through the link below.
